Site Lighting Plan

Precision, Performance, and Aesthetic Illumination for Every Project

At FutureGen Consulting Inc., we believe that lighting is more than just a utility—it’s a strategic design element that enhances safety, reinforces site functionality, and contributes to the overall visual identity of a space. Whether it’s a retail plaza, a residential complex, or an industrial facility, a thoughtfully designed Site Lighting Plan is essential for operational success and community approval.

As a leading engineering firm based in Ontario, we specialize in crafting code-compliant, energy-efficient, and visually balanced lighting layouts that address both functional and architectural needs. Our plans are tailored to ensure that your site is safe, navigable, and beautifully illuminated—while meeting all applicable municipal, provincial, and industry standards.

Why a Site Lighting Plan Matters

A professionally developed site lighting plan is required for nearly all commercial and residential development applications. Municipalities often request a photometric layout during the site plan approval stage to assess how light will be distributed across the property. Improper lighting can lead to permit delays, safety concerns, and even long-term operational inefficiencies.

With increasing emphasis on energy conservation and responsible design, municipalities are also cracking down on light pollution, glare, and excessive energy consumption. Our lighting plans help you navigate these challenges, ensuring:

• Adequate Illumination for safety and visibility

• Light Uniformity to avoid dark zones or overlit areas

• Glare Control for vehicle and pedestrian comfort

• Dark Sky Compliance to reduce upward light pollution

• Energy Efficiency using LED technology and automated controls

• Code Compliance with Ontario Building Code, municipal bylaws, and IESNA standards

What’s Included in Our Site Lighting Design Package

We provide full-service site lighting design packages that can be submitted directly to municipalities or integrated into your site plan set. Each design includes:

1. Photometric Lighting Layout

We simulate and map light levels using industry-standard software like Dialux or AGi32. Our calculations show foot-candle levels across drive aisles, sidewalks, parking areas, entrances, and landscaped regions.

2. Pole and Fixture Placement

We determine optimal locations for light poles based on site geometry, mounting heights, setbacks, and lighting distribution. Fixtures are carefully selected for beam spread, tilt angle, and lumen output to maximize efficiency.

3. Fixture Cut Sheets and Specifications

Every project includes detailed fixture specifications that align with your site’s architecture and lighting goals. Whether it’s wall-mounted lights for building perimeters or pole-mounted luminaires for open spaces, we ensure the selected products match photometric performance.

4. Lighting Controls Strategy

We incorporate smart lighting controls—motion sensors, daylight sensors, or timers—to help reduce energy consumption and comply with Ontario energy codes.

5. Electrical Connection Notes

Our drawings include general power supply requirements, panel sizing guidance, and basic load summaries for electrical coordination.

6. Municipal Submission Package

We deliver drawings in both PDF and CAD formats, ready for direct submission to city authorities or integration into a broader site plan submission.

Types of Sites We Serve

Our lighting plans are custom-designed to meet the specific needs of each site. These include:

► Commercial Sites

Retail plazas, office parks, shopping centers, and standalone commercial buildings require even, glare-free lighting for pedestrian and vehicle zones. We create layouts that enhance storefront visibility and meet zoning regulations.

► Residential Subdivisions and Condos

For multi-unit housing or townhome developments, we design lighting that promotes comfort, visibility, and a sense of security—while being sensitive to nearby properties.

► Industrial and Logistics Sites

Warehouses, truck yards, and storage facilities need powerful and consistent lighting for night operations. We ensure visibility across all operational zones without creating excessive spillover.

► Institutional and Public Infrastructure

Schools, community centers, transit terminals, and parks benefit from safe, uniform lighting that supports public use, emergency access, and ADA-compliant pathways.

Benefits of Choosing FutureGen Consulting Inc.

Our clients trust us because we combine engineering precision with a deep understanding of architectural context and regulatory expectations. Here’s what makes us different:

✔ Local Experience

We’re based in Mississauga, Ontario, and have completed lighting designs for dozens of municipalities across the GTA and beyond. We understand regional guidelines, approval processes, and local utility requirements.

✔ In-House Lighting Simulation

We use professional photometric software and lighting databases, ensuring high accuracy in our models and layouts. You get clear, easy-to-read visuals that demonstrate compliance and performance.

✔ Fast Turnaround & Clear Communication

Need a quick lighting layout for a resubmission or last-minute revision? We pride ourselves on responsive service, clear deliverables, and practical coordination with your architect or civil team.

✔ Integration With Full MEP Services

As a multi-disciplinary engineering firm, we can integrate lighting with electrical panel design, power calculations, and broader mechanical/electrical engineering services—offering you a one-stop solution.

Our Process: From Concept to Permit Approval

Here’s how we typically approach a Site Lighting Plan project:

1. Site Review & Requirements Gathering
   We start with your architectural or civil site plan and review zoning conditions, site usage patterns, security needs, and any municipal guidelines.

2. Preliminary Layout & Fixture Selection
   Based on coverage areas and mounting constraints, we draft a fixture layout and recommend pole types and fixture families for your review.

3. Photometric Modeling
   We simulate your site lighting performance and generate heatmaps, iso-contours, and vertical/horizontal lighting levels.

4. Final Package Submission
   After your feedback, we finalize the drawings and provide digital deliverables suitable for planning applications or permit packages.

Ready to Illuminate Your Project?

Let us help you achieve a lighting plan that not only meets the code—but exceeds expectations in safety, aesthetics, and long-term performance.

📞 Contact FutureGen Consulting Inc. today to discuss your site lighting needs, or send us your site plan for a free initial review.
